25+ Raspberry Compatible 1-Wire Host Boards/Hats

(sortable)

Image Name / Link Channels (Buses) Extras Price Price per channel
1-Wire Driver
DS2482-800
8 ch. --- £21.05 £2.63 / ch
1-Wire Interface
Module
1 ch. --- £5.93 £5.93 / ch
R-Pi i2c 1-Wire OWFS Expansion Module 1 ch. --- £17.99 £17.99 / ch
I2C counter /
1-wire board
8 ch. 6x 16 bit Counter inputs £69.99 £8.75 / ch
Com Pi 1 ch. RS232 Port £12.99 £12.99 / ch
1 Wire Pi Plus 1 ch. --- £12 £12 / ch
RP1 1-Wire GPIO Host Adapter 1 ch. --- £7.95 £7.95 / ch
RPI2 1-Wire Host Adapter 1 ch. --- £14 £13.95 / ch
RPI3 v1 1-Wire Host Adapter 8 ch. RTC £33 £4.12 / ch
RPI3 v2 1-Wire Host Adapter 8 ch. RTC £33 £4.12 / ch
AbioWire+ 17 ch. --- £42 £5.25 / ch
1-Wire Mini Host 8 ch. --- £15.26 £1.90 / ch
1-Wire Automation System 8 ch. expansion slot £114 £14.25 / ch
Raspberry Pi -9 Channel 1-Wire Board 9 ch. RTC £33 £3.66 / ch
IoT-1Wire-1 module Board 8 ch. --- £34 £4.25 / ch
IoT-1Wire-1 module Board 1 ch. (5 ports) --- £24 £24 / ch
4 USB Hub & I2C AD/DA - 1-Wire   Board 1 ch. RTC, 10bit ADC, 8bit DAC, 4 USB Hub £52 £52 / ch
7 USB Hub & I2C AD/DA - 1-Wire   Board 1 ch. 10bit ADC / 8bit DAC, 7 USB Hub £58 £58 / ch
Step Motor & I2C 1-Wire Board 1 ch. 8 ch output / step motor output  £21 £21 / ch
One-Wire 17 Channels 17 ch. --- £46.99 £2.76 / ch
USB to One Wire converter 1 ch. --- $24.60 $24.60 / ch
S4: USB / 1-Wire Interface Card 1 ch. --- €39 €39 / ch
USB to 1-Wire RJ11 1 ch. --- £26 £26 / ch
I2C 1 Wire Click 8 ch. --- £19.45 £2.43 / ch
UART to 1 Wire Adapter (Retired)  1 ch. --- --- ---
UniPi Expansion Board 1 ch. Relays, Inputs, Outputs, Analog In/Out 0-10v $134 $134 / ch
PIGATOR Onewire 1 ch.  RTC, uplink header for expansion £60 £60 / ch
